E6582175
A-1
1
1. Read first
1.1 Check product purchase
Before using the product you have purchased, check to make sure that it is exactly what you ordered.
Caution
Mandatory
action
Use an inverter that conforms to the specifications of power supply and three-phase induction
motor being used. If the inverter being used does not conform to those specifications, not only will
the three-phase induction motor not rotate correctly, but it can also cause serious accidents
through overheating and fire.
Inverter Type
Inverter rated
output capacity
Power supply
Rated input
current
Rated output
current
Model
Power supply
Motor capacity
Inverter main unit
Carton box
Name plate
Danger label
Type indication label
Name plate
Setup sheet
Danger label
Rating label
Rating label
