Toshiba Tosvert VF-S15 User Manual

E6582175
F-123
6
6.33 Adjustment parameters
6.33.1 Inputting integral input power pulse
 : Integral input power pulse output unit
 : Integral input power pulse output width
 Function
Pulse signal can be output each time integral input power reaches integral power unit that is set by
f667.
Pulse output width is set by
f668.
[Parameter setting]
Title Function Adjustment range Default setting

Integral input power pulse output unit
0: 0.1kWh
1: 1kWh
2: 10kWh
3: 100kWh
1

Integral input power pulse output width
0.1-1.0 (s)
0.1
Setting example) When integral input power pulse is output from output terminal
Title Function Adjustment range Setting

Output terminal selection 2A 0 - 255
180:
IPU (Integral input
power pulse output signal)
There is no reverse signal.
6.33.2 Pulse train output for meters
f669 : Logic output/pulse train output selection (OUT)
f676 : Pulse train output function selection (OUT)
f677 : Maximum numbers of pulse train output
f678 : Pulse train output filter
 Function
Pulse trains can be sent out through the OUT output terminals.
Set a pulse output mode and the number of pulses.
Ex.: When operations frequencies (0 to 60Hz) are put out by means of 0 to 600 pulses
fh=60.0, f669=1, f676=0, f677=0.60

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
