11.5 Default settings by setup menu
Function Title
Main regions
eu
(Europe)
asia
(Asia,
Oceania)
usa
(North
America)

(Japan)
Frequency
ul/
vl/
f170 /
f204 /
f213 /
f219 /
f330 /
f367 /
f814
50.0(Hz) 50.0(Hz)
60.0(Hz) 60.0(Hz)
Base
frequency
voltage 1, 2
240V class
vlv/
f171
230(V) 230(V) 230(V) 200(V)
500V class
400(V) 400(V) 460(V)
400(V)
V/F control mode selection
pt
0 0
0 2
Supply voltage correction
(output voltage limitation)
f307
2 2 2 3
Regenerative over-
excitation upper limit
f319
120 120 120 140
Motor rated speed
f417
Refer to section 11.4
Note1) Refer to section 3.1 about setup menu.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
