E6582175
K-42
11
11.7 Output Terminal Function
It can be assigned the function No. in the following table to parameter f130 to f138, f157, f158.
Table of output terminal functions 1
Function
No.
Code Function Action Reference
0 LL Frequency lower limit ON: Output frequency is more than
OFF: Output frequency is or less
5.4
1 LLN Inversion of frequency lower limit Inversion of LL
2 UL Frequency upper limit ON: Output frequency is or more
OFF: Output frequency is less than
3 ULN Inversion of frequency upper limit Inversion of UL
4 LOW Low-speed detection signal ON: Output frequency is or more
OFF: Output frequency is less than
6.5.1
7.2.2
5 LOWN Inversion of low-speed detection signal Inversion of LOW
6 RCH Output frequency attainment signal
(acceleration/deceleration completed)
ON: Output frequency is within command frequency
OFF: Output frequency is more than command frequency
6.5.2
7.2.2
7 RCHN Inversion of output frequency attainment
signal
(inversion of acceleration/deceleration
completed)
Inversion of RCH
8 RCHF Set frequency attainment signal ON: Output frequency is within ±
OFF: Output frequency is more than ±
6.5.3
9 RCHFN Inversion of set frequency attainment signal Inversion of RCHF
10 FL Fault signal (trip output) ON: Inverter tripped
OFF: Inverter not tripped
7.2.2
11 FLN Inversion of fault signal (inversion of trip
output)
Inversion of FL
14 POC Over-current detection pre-alarm ON: Output current is or more
OFF: Output current is less than
6.29.2
15 POCN Inversion of over-current detection pre-alarm Inversion of POC
16 POL Overload detection pre-alarm ON: (%) or more of calculated value of overload
protection level
OFF: Less than (%) of calculated value of overload
protection level
5.6
17 POLN Inversion of overload detection pre-alarm Inversion of POL
20 POH Overheat detection pre-alarm
ON: Approx. 95C or more of IGBT element
OFF: Less than approx. 95C of IGBT element (90C or less
after detection is turned on)
7.2.2
21 POHN Inversion of overheat detection pre-alarm Inversion of POH
22 POP Overvoltage detection pre-alarm ON: Power circuit voltage is f626 or more
OFF: Power circuit voltage is under f626
6.19.5
23 POPN Inversion of overvoltage detection pre-alarm Inversion of POP
24 MOFF Power circuit undervoltage detection ON: Power circuit undervoltage (moff) detected
OFF: Undervoltage detection canceled
6.29.13
25 MOFFN Inversion of power circuit undervoltage
detection
Inversion of MOFF
26 UC Small current detection ON: After output current comes to or less, value of
less than + for set time
OFF: Output current is more than
(+ or more after detection turns on)
6.29.7
27 UCN Inversion of small current detection Inversion of UC
28 OT Over-torque detection ON: After torque comes to or more, value of more
than - for set time
OFF: Torque is less than
(-or less after detection turns on)
6.29.10
29 OTN Inversion of over-torque detection Inversion of OT
