Toshiba Tosvert VF-S15 User Manual

E6582175
F-146
6
6.38.4 Open network option
c700 to c789 , c800 to c830 : CANopen communication
parameters
c001 to c111 , c160 to c164 : Communication option common
c885 to c896 , c900 to c999 parameters
c120 to c148 : CC-Link option parameters
c150 to c159 : PROFIBUS DP option parameters
c200 to c203 : DeviceNet option parameters
c400 to c421 , c850 to c880 : EtherCAT option parameters
c500 to c536 : EtherNet common parameters
c554 to c556 : EtherNet/IP option parameters
c600 to c604 : Modbus TCP option parameters
● CANopen option (Type: CAN001Z, CAN002Z, CAN003Z)
CC- Link option (Type: CCL003Z)
PROFIBUS DP option (Type: PDP003Z)
DeviceNet option (Type: DEV003Z)
EtherNet / IP-Modbus TCP option (Type: IPE002Z)
EtherCAT option (Type: IPE003Z)
 Refer to each Instruction Manual of option for details.
6.39 Permanent magnet motors
f910 : Step-out detection current level
f911 : Step-out detection time
f912 : q-axis inductance
f913 : d-axis inductance
f915 : Factory specific coefficient 9L
 Function
If the permanent magnet motor (PM motor) steps out and if the exciting current increases (it increases
in such a case) and remains above the value set with
f910 for the period of time set with f911,
the inverter will judge the motor to be stepping out and trip it. At that time, the trip message
"
sout" is displayed.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
