12. Specifications
12.1 Models and their standard specifications
 Standard specifications
Item Specification
Input voltage 3-phase 240V
Applicable motor (kW) 0.4 0.75 1.5 2.2 4.0 5.5 7.5 11 15
Rating
Type VFS15
Form 2004PM-W1 2007PM-W1 2015PM-W1 2022PM-W1 2037PM-W1 2055PM-W1 2075PM-W1 2110PM-W1 2150PM-W1
Capacity (kVA) Note 1) 1.3 1.8 3.0 4.2 6.7 10.5 12.6 20.6 25.1
Rated output current
(A) Note 2)
3.3
(3.3)
4.8
(4.4)
8.0
(7.9)
11.0
(10.0)
17.5
(16.4)
27.5
(25.0)
33.0
(33.0)
54.0
(49.0)
66.0
(60.0)
Output voltage Note 3) 3-phase 200V to 240V
Overload current rating
150％-60 seconds, 200%-0.5 second
Power supply
Voltage-frequency 3-phase 200V to 240V - 50/60Hz
Allowable fluctuation Voltage 170V to 264V Note 4), frequency ±5%
Required Power supply
capacity (kVA) Note 5)
1.4 2.5 4.3 5.7 9.2 13.8 17.8 24.3 31.6
Protective method (IEC60529) IP20
Cooling method Self-cooling Forced air-cooled
Color RAL7016
Built-in filter Basic filter
Item Specification
Input voltage 1-phase 240V 3-phase 500V
Applicable motor (kW) 0.2 0.4 0.75 1.5 2.2 0.4 0.75 1.5 2.2 4.0 5.5 7.5 11 15
Rating
Type VFS15S VFS15
Form
2002PL
-W1
2004PL
-W1
2007PL
-W1
2015PL
-W1
2022PL
-W1
4004PL
-W1
4007PL
-W1
4015PL
-W1
4022PL
-W1
4037PL
-W1
4055PL
-W1
4075PL
-W1
4110PL
-W1
4150PL
-W1
Capacity (kVA) Note 1) 0.6 1.3 1.8 3.0 4.2 1.1 1.8 3.1 4.2 7.2 10.9 13.0 21.1 25.1
Rated output current
(A) Note 2)
1.5
(1.5)
3.3
(3.3)
4.8
(4.4)
8.0
(7.9)
11.0
(10.0)
1.5
(1.5)
2.3
(2.1)
4.1
(3.7)
5.5
(5.0)
9.5
(8.6)
14.3
(13.0)
17.0
(17.0)
27.7
(25.0)
33.0
(30.0)
Rated output voltage Note 3) 3-phase 200V to 240V 3-phase 380V to 500V
Overload current rating
150％-60 seconds, 200%-0.5 second 150％-60 seconds, 200% -0.5 second
Power supply
Voltage- frequency 1-phase 200V to 240V – 50/60Hz 3-phase 380V to 500V - 50/60Hz
Allowable fluctuation
Voltage 170V to 264V Note 4),
frequency±5％
Voltage 323V to 550V Note 4), frequency ±5%
Required Power supply
capacity (kVA) Note 5)
0.8 1.4 2.3 4.0 5.4 1.6 2.7 4.7 6.4 10.0 15.2 19.5 26.9 34.9
Protective method (IEC60529) IP20 IP20
Cooling method Self-cooling
Forced air-
cooled
Forced air-cooled
Color RAL7016 RAL7016
Built-in filter EMC filter EMC filter
Note 1. Capacity is calculated at 220V for the 240V models, at 440V for the 500V models.
Note 2. Indicates rated output current setting when the PWM carrier frequency (parameter f300) is 4kHz or less. When
exceeding 4kHz, the rated output current setting is indicated in the parentheses. It needs to be further reduced for
PWM carrier frequencies above 12 kHz.
The rated output current is reduced even further for 500V models with a supply voltage of 480V or more.
The default setting of the PWM carrier frequency is 12kHz.
Note 3. Maximum output voltage is the same as the input voltage.
Note 4. At 180V-264V for the 240V models, at 342V-550V for the 500V models when the inverter is used continuously (load of
100%).

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
