Toshiba Tosvert VF-S15 - Page 337

E6582175
K-38
11
 Table of input terminal functions 2
Function
No.
Code Function Action Reference
52 IDC PID integral/differential clear ON: Integral/differential clear, OFF: Clear canceled 6.24
53 IDCN Inversion of PID integral/differential clear Inversion of IDC
54 DR PID characteristics switching ON: Inverted characteristics of  selection
OFF: Characteristics of  selection
55 DRN Inversion of PID characteristics switching Inversion of DR
56 FORCE Forced run operation ON: Forced run operation if specified faults are occurred
( frequency)
OFF: Normal operation
6.30
57 FORCEN Inversion of forced run operation Inversion of FORCE
58 FIRE Fire speed operation ON: Fire speed operation ( frequency)
OFF: Normal operation
59 FIREN Inversion of fire speed operation Inversion of FIRE
60 DWELL Acceleration/deceleration suspend signal ON: Acceleration/deceleration suspend
OFF: Normal operation
6.23
61 DWELLN Inversion of acceleration/deceleration
suspend signal
Inversion of DWELL
62 KEB Power failure synchronized signal ON: Deceleration stop with synchronizing when power failure
OFF: Normal operation
6.19.2
63 KEBN Inversion of power failure synchronized signal Inversion of KEB
64, 65 Factory specific coefficient - *1
70, 71 Factory specific coefficient - *1
74 CKWH Integrating wattmeter(kWh) display clear ON: Integrating wattmeter(kwh) monitor display clear
OFF: Disabled
6.36
75 CKWHN Inversion of integrating wattmeter display clear Inversion of CKWH
76 TRACE Trace back trigger signal ON: Trigger(start) signal of trace function
OFF: Disabled
6.35
77 TRACEN Inversion of trace back trigger signal Inversion of TRACE
78 HSLL Light-load high-speed operation prohibitive
signal
ON: Light-load high-speed operation prohibited
OFF: Light-load high-speed operation permitted
6.21
79 HSLLN Inversion of light-load high-speed operation
prohibitive signal
Inversion of HSLL
80 HDRY Holding of RY-RC terminal output ON: Once turned on, RY-RC are held on.
OFF: The status of RY-RC changes in real time according to
conditions.
7.2.2
81 HDRYN Inversion of holding of RY-RC terminal output Inversion of HDRY
82 HDOUT Holding of OUT-NO terminal output ON: Once turned on, OUT-NO are held on.
OFF: The status of OUT-NO changes in real time according
to conditions.
83 HDOUTN Inversion of holding of OUT-NO terminal output Inversion of HDOUT
88 UP Frequency UP ON: Frequency increased
OFF: Frequency increase canceled
6.10.4
89 UPN Inversion of frequency UP Inversion of UP
90 DWN Frequency DOWN ON: Frequency decreased
OFF: Frequency decrease canceled
91 DWNN Inversion of frequency DOWN Inversion of DWN
92 CLR Clear frequency UP/DOWN OFF  ON: Clear frequency UP/DOWN
93 CLRN Inversion of clear frequency UP/DOWN Inversion of CLR
96 FRR Coast stop command ON: Coast stop (Gate OFF)
OFF: Coast stop canceled
3.2.1
6.34.8
97 FRRN Inversion of coast stop command Inversion of FRR
98 FR Forward/reverse selection ON: Reverse command
OFF: Forward command
7.2.1
99 FRN Inversion of forward/reverse selection Inversion of FR
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
