E6582175
K-39
11
Table of input terminal functions 3
Function
No.
Code Function Action Reference
100 RS Run/Stop command ON: Run command
OFF: Stop command
7.2.1
101 RSN Inversion of run/Stop command Inversion of RS
104 FCHG Frequency setting mode forced switching ON: f207 (f200=0)
OFF: fmod
6.2.1
105 FCHGN Inversion of frequency setting mode forced
switching
Inversion of FCHG
106 FMTB Frequency setting mode terminal block ON: Terminal block (VIA) enabled
OFF: Setting of
107 FMTBN Inversion of frequency setting mode terminal
block
Inversion of FMTB
108 CMTB Command mode terminal block ON: Terminal block enabled
OFF: Setting of
109 CMTBN Inversion of command mode terminal block Inversion of CMTB
110 PWE Parameter editing permission ON: Parameter editing permitted
OFF: Setting of
6.34.1
111 PWEN Inversion of parameter editing permission Inversion of PWE
120 FSTP1 Fast stop command 1 ON: Dynamic quick deceleration command
OFF: Forced deceleration canceled
(Note that operation is resumed when forced deceleration is canceled)
6.1.4
121 FSTP1N Inversion of fast stop command 1 Inversion of FSTP1
122 FSTP2 Fast stop command 2 ON: Automatic deceleration
OFF: Forced deceleration canceled
(Note that operation is resumed when forced deceleration is canceled)
123 FSTP2N Inversion of fast stop command 2 Inversion of FSTP2
134 TVS Traverse permission signal ON: Permission signal of traverse operation
OFF: Normal operation
6.40
135 TVSN Inversion of traverse permission signal Inversion of TVS
136 RSC Low voltage operation signal ON: Low voltage operation
OFF: Low voltage operation canceled
6.17
137 RSCN Inversion of low voltage operation signal Inversion of RSC
140 SLOWF Forward deceleration ON: Forward operation with f383 frequency
OFF: Normal operation
6.22.2
141 SLOWFN Inversion of forward deceleration Inversion of SLOWF
142 STOPF Forward stop ON: Forward stop, OFF: Normal operation
143 STOPFN Inversion of forward stop Inversion of STOPF
144 SLOWR Reverse deceleration ON: Reverse operation with f383 frequency
OFF: Normal operation
145 SLOWRN Inversion of reverse deceleration Inversion of SLOWR
146 STOPR Reverse stop ON: Reverse stop, OFF: Normal operation
147 STOPRN Inversion of reverse stop Inversion of STOPR
148 to 151 Factory specific coefficient - *1
152 MOT2 No.2 motor switching
（AD2＋VF2＋OCS2）
ON: No.2 motor
(=0, , , , (thr when
f632=2 or 3), , , , )
OFF: No.1 motor (Set value of , , , , ,
, , , )
6.8.1
153 MOT2N Inversion of No.2 motor switching
（AD2＋VF2＋OCS2）
Inversion of MOT2
158 RES2 Reset command 2 *2 ON: Trip reset 13.2
159 RES2N Inversion of reset command 2 *2 Inversion of RES2
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*2: These functions are cannot be assigned to Always active function selection 1 to 3 (f104, f108, f110).
