Toshiba Tosvert VF-S15 User Manual

E6582175
F-12
6
When vector control cannot be programmed....
First read the precautions about vector control in section 6.3.9).
1) If the desired torque cannot be obtained  Refer to section 6.25 selection 2
2) If auto-tuning error "" appears  Refer to section 6.25 selection 4
  (Torque boost setting macro function) and  (V/F control mode
selection)
Automatic torque boost is the parameter for setting V/F control mode selection () and auto-tuning
() together. That is why all parameters related to change automatically when  is changed.
Automatically programmed parameters
  

Displays  after resetting - Check the programmed value of . -

Automatic torque boost +
auto-tuning

Automatic torque boost control

Auto-tuning
executed
(after execution: 0)

Vector control + auto-tuning

Vector control

Auto-tuning
executed
(after execution: 0)

Energy saving + auto-tuning

Energy-saving

Auto-tuning
executed
(after execution: 0)
4) Increasing torque manually (V/F constant control)
This is the setting of constant torque characteristics that are suited for such things as conveyors. It can also
be used to manually increase starting torque.
If V/F constant control is programmed after changing ,
Set V/F control mode selection  =  (V/F constant).
 Refer to section 6.3
Note 7: To further increase torque, increase the torque boost value 1().
How to set the torque boost value 1()  Refer to section 6.4
Note 8: V/F control selection = 1 (variable torque) is an effective setting for load such as fans and
pumps.  Refer to section 6.3

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
