Toshiba Tosvert VF-S15 User Manual

E6582175
F-52
6
 Panel jog mode (if f262 is set to 1)
 The direction of rotation can change by using extension panel.
Using RKP007Z : Display switches to fjog and rjog by every pressing the FWD/REV key.
Using RKP002Z : Pressing the UP key changes display to fjog and pressing the DOWN key
changes display to rjog.
 When fjog is displayed, the inverter will be placed in forward jog run mode as long as the
key is pressed.
 When rjog is displayed, the inverter will be placed in reverse jog run mode as long as the
key is pressed.
 If you press and hold down the key for 20 seconds or more, the key failure alarm “e-17” will
be displayed.
Here is the sequence in which modes change each time you press the key.
Standard monitor
mod e
Status monitor
mod e
Setting monitor
mod e
Pan el jo g mod e
MODE
MOD E
MOD E
MODE
Note: When the inverter is in operation (RUN lamp is blinking) or when an operation command is issued
(RUN lamp is lighting), the inverter cannot be switched to panel jog mode.
RUN
RUN
MODE

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
