Toshiba Tosvert VF-S15 User Manual

E6582175
F-62
6
In case of aul=2 (Variable torque characteristic (120%-60s)) setting.
VFS15-
Ambient
temperature
PWM carrier frequency
2.0k~4.0kHz
4004PL-W1
40C or less
2.1 A
4007PL-W1
40C or less
3.0 A
4015PL-W1
40C or less
5.4A
4022PL-W1
40C or less
6.9 A
4037PL-W1
40C or less
11.1 A
4055PL-W1
40C or less
17.0A
4075PL-W1
40C or less
23.0 A
4110PL-W1
40C or less
31.0A
4150PL-W1
40C or less
38.0A
* In case of =2 setting, be sure to install the input AC reactor (ACL) between power supply and inverter,
to remove the protective label on the top of the inverter, and to connect the grounding capacitors by pressing
the grounding capacitor switch.
Then, to use the inverter at 40°C or less of the ambient temperature with setting f300 to 4.0 kHz or less.
* If parameter f316=0, 2 or 4 and current is increased to main module overheat level (ol3) or to
overheat level (oh), the l alarm or h alarm occurs. If the cumulative amount of overload is increased further,
ol3 trip or oh trip occurs.
In this case, to avoid such trips, reduce the stall prevention level (f601) properly.
* PWM carrier frequency is increased at high output frequency area for stable operation, even if f300 is set
to low PWM carrier frequency.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
