Toshiba Tosvert VF-S15 User Manual

E6582175
F-71
6
[Parameter setting]
Title Function Setting
f304
Dynamic braking selection 1
f305
Overvoltage limit operation 1
f308
Dynamic braking resistance Proper value
f309
Dynamic braking resistor capacity Proper value
f626
Over-voltage stall protection level
136 (%) (240V class)
141 (%) (500V class)
● To use this inverter in applications that create a continuously regenerative status (such as downward
movement of a lift, a press or a tension control machine), or in applications that require deceleration
stopping of a machine with a significant load inertial moment, increase the dynamic braking resistor
capacity according to the operation rate required.
● To connect an external dynamic braking resistor, select one with a resultant resistance value greater than
the minimum allowable resistance value. Be sure to set the appropriate operation rate in f308 and
f309 to ensure overload protection.
● When using a braking resistor with no thermal fuse, connect and use a thermal relay as a control circuit for
cutting the power off.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
