E6582175
F-90
6
[Selection 4: Setting vector control and manual tuning independently]
If an "etn1" tuning error is displayed during auto-tuning or when vector control characteristics are to be
improved, set independent motor constants. If an "etn1" tuning error is displayed, Set f400 to 0.
[Parameter setting]
Title Function Adjustment range Default setting
f401
Slip frequency gain
0-250 (%）
70
f402
Automatic torque boost value 0.1-30.0 (%)
Depends on the capacity
(Refer to section 11.4)
f405
Motor rated capacity 0.01-22.00 (kW)
f415
Motor rated current 0.01-100.0 (A)
f416
Motor no-load current 10-90 (%)
f417
Motor rated speed 100-64000 (min
-1
)
Depends on the capacity
(Refer to section 11.4)
*1
f459
Load inertia moment ratio 0.1-100.0 (times) 1.5
f462
Speed reference filter coefficient 0-100 35
thr
Motor electronic thermal
protection level 1
10-100 (%) / (A) 100
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
Setting procedure Adjust the following parameters:
f401: Set the compensation gain for the slipping of the motor. A higher slip frequency reduces motor
slipping correspondingly. After setting f417, set f401 for fine adjustment. Be careful as
inputting a value larger than necessary causes hunting and other unstable operation.
f402: Adjust the primary resistive component of the motor. Torque reduction due to possible voltage drop
during low-speed operation can be suppressed by setting a large value in this parameter. Be
careful as setting a value larger than necessary may lead to an increased current and then cause
a trip at low speeds. (Perform adjustments according to the actual operation.)
f405: Set the motor's rated capacity according to the motor's name plate or test report.
f415: Set the rated current of the motor. For the rated current, see the motor's nameplate or test report.
f416: Set the ratio of the no-load current of the motor to the rated current. Enter the value in % that is
obtained by dividing the no-load current specified in the motor's test report by the rated current. A
larger value increases the excitation current.
f417: Set the rated rotational speed of the motor. For the rated current, see the motor's nameplate or test
report.
● Adjustment method for the moment of inertia of the load
f459: Adjusts the excess response speed. A larger value gives a smaller overshoot at the
acceleration/deceleration completion point. In the default settings, the moment of inertia of the load
(including the motor shaft) value is optimally set considering a motor shaft of 1.5x. When the
moment of inertia of the load is not 1.5x, set a value that matches that actual moment of inertia of
the load.
thr : If the rated capacity of the motor is one size smaller than that of the inverter, lower the thermal
protective level according to the rated current of the motor.
Caution:
If a combination of the inverter rating and the motor capacity is different for more than 2 classes,
vector control may not operate correctly.
