Toshiba Tosvert VF-S15 User Manual

E6582175
F-114
6
=: Inverter is stopped. However, it is not tripped (Failure signal FL not activated). The inverter stop
(Failure signal FL not activated.), only after detection of a voltage not exceeding 50% of its rating.
Be sure to connect the input AC or DC reactor specified in section 10.4.
[Parameter setting]
Title Function Adjustment range Default setting
f627
Undervoltage trip/alarm
selection
0: Alarm onl
y
(detection level 60% or less)
1: Tripping
(detection level 60% or less)
2: Alarm only
(detection level 50% or less, input
AC or DC reactor required)
3: -
0
6.29.14 Analog input break detection
f633 : Analog input break detection level (VIC)
f644 : Operation selection of analog input break detection (VIC)
f649 : Fallback frequency
 Function
The inverter will output a trip or an alarm, if the VIC value remains below the specified value for about
0.3 seconds. In such a case, trip "
e-18" and alarm "a-18" is displayed.
f633=0: Disabled....Not detected.
f633=1-100....The inverter will output a trip or an alarm, if the VIC input remains below the specified value
for about 0.3 seconds.
[Parameter setting]
Title Function Adjustment range Default setting
f633
Analog input break detection level
(VIC)
0: Disabled
1-100%
0
f644
Operation selection of analog input
break detection (VIC)
0: Tripping
1: Alarm only (Coast stop)
2: Alarm only (
f649 frequency)
3: Alarm only (Maintain running)
4: Alarm only (Deceleration stop)
0
f649
Fallback frequency
ll-ul(Hz)
0.0
Note : The VIC input value may be judged earlier to be abnormal, depending on the degree of deviation of
the analog data detected.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
