E6582175
F-141
6
Title Function Adjustment range Default setting
f856
Number of motor poles for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
f870
Block write data 1
0: No selection
1: Communication command 1
2: Communication command 2
3: Frequency command value
4: Output data on the terminal
block
5: FM analog output
6: Motor speed command
0
f871
Block write data 2 0
f875
Block read data 1
0: No selection
1: Status information 1
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal monitor
8: Output terminal monitor
9: Terminal VIA monitor
10: Terminal VIB monitor
11: Terminal VIC monitor
12: Input voltage (DC detection)
13: Motor speed
14: Torque
0
f876
Block read data 2 0
f877
Block read data 3 0
f878
Block read data 4 0
f879
Block read data 5 0
f899
Communication function reset
0: -
1: Reset (after execution: 0)
0
*1: Disabled ........... Indicates that the inverter will not be tripped even if a communication error occurs.
Trip ................... The inverter trips when a communication time-over occurs.
In this case a trip information
err5 flashes on and off on the operation panel.
Alarm ................ When a communication time-over occurs, an alarm can be output from the output terminal.
Output terminal function: 78 (RS485 communication error) or 79 (RS485 communication
error reverse)
*2: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
Note2) Changes to the parameters
f800, f801 and f806 do not take effect until the power is turned
off and then on again.
