E6582175
H-10
8
Parameter Setting No. LED display Function Unit
Communication No.
to ,
f720
0 x60.0 Output frequency Hz / free unit FE00
1 c16.5 Output current *1 % / A FC02
2 f50.0 Frequency command value Hz / free unit FE02
3 y100 Input voltage (DC detection) *1 % / V FC05
4 p 90 Output voltage (command value) *1 % / V FC08
5 k 3.0 Input power *1 kW FC06
6 h 2.8 Output power *1 kW FC07
7 q 80 Torque *1, *2 % FC04
9 g 60 Motor cumulative load factor % FE23
10 l 80 Inverter cumulative load factor % FE24
11 r 80 PBR (Braking resistor) cumulative load factor % FE25
12 b51.0 Stator frequency Hz / free unit FE15
13 a 65 VIA input value % FE35
14 b 45 VIB input value *2 % FE36
18 *3 Arbitrary code from communication *3 *3
20 c 35 VIC input value % FE37
21 p800 Pulse train input value pps FE56
23 d40.0 PID feedback value Hz / free unit FE22
24 k356 Integral input power
Depend on
f749
FE76
25 h348 Integral output power
Depend on
f749
FE77
26 g 75 Motor load factor % FE26
27 l 70 Inverter load factor % FE27
28 a33.0 Inverter rated current A FE70
29 f 70 FM output value % FE40
30 p800 Pulse train output value pps FD40
31 p34.5 Cumulative power on time 100 hours FE80
32 f28.6 Cumulative fan operation time 100 hours FD41
33 t27.7 Cumulative operation time 100 hours FD14
34 n89.0 Number of starting times 10000 times FD32
35 f45.5 Forward number of starting times 10000 times FD33
36 r43.5 Reverse number of starting times 10000 times FD34
37 a 2 Number of trip times FD35
40 a33.0
Inverter rated current (Carrier frequency
corrected)
A FD70
52 w50.0
During stop : Frequency command value
During operation : Output frequency
Hz / free unit FE99
53 r 80 PBR (Braking resistor) load factor % FD28
