Toshiba Tosvert VF-S15 - Page 305

E6582175
K-6
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0130 Output terminal
selection 1A
(RY-RC)
- -
0-255 *7
4
(LOW)
6.7.3
7.2.2

0131 Output terminal
selection 2A (OUT)
- - 6
(RCH)

0132 Output terminal
selection 3 (FL)
- - 10
(FL)

0137 Output terminal
selection 1B
(RY-RC)
- - 255
(always
ON)

0138 Output terminal
selection 2B (OUT)
- - 255
(always
ON)

0139 Output terminal
logic selection
(RY-RC, OUT)
- - 0:  and 
 and 
0
1:  or 
 and 
2:  and 
 or 
3:  or 
 or 

0144 Input terminal
response time
ms 1/1 1-1000 1 6.7.2
7.2.1

0146 Logic input / pulse
train input
selection (S2)
- - 0: Logic input
1: Pulse train input
0 6.7.2
6.10.5
7.2.1

0147 Logic input / PTC
input selection (S3)
- - 0: Logic input
1: PTC input
0 2.3.2
6.7.2
6.29.16
7.2.1

0151 Input terminal
selection 1B (F)
- -
0-203 *6
0 6.7.2
7.2.1

0152 Input terminal
selection 2B (R)
- - 0

0153 Input terminal
selection 3B (RES)
- - 0

0154 Input terminal
selection 4B (S1)
- - 0

0155 Input terminal
selection 1C (F)
- - 0

0156 Input terminal
selection 2C (R)
- - 0

0167 PID set value
agreement
detection range
Hz 0.1/0.01 0.0- 2.5 6.24
*6: Refer to section 11.6 for details about input terminal function.
*7: Refer to section 11.7 for details about output terminal function.
