Table of output terminal functions 4
Function
No.
Code Function Action Reference
144 PIDF Signal in accordance of PID set value ON: PID set value by is within ± of .
OFF: Other than those above
6.24
145 PIDFN Inversion of signal in accordance of PID set
value
Inversion of PIDF
146 FLR Fault signal (output also at a retry waiting) ON: While inverter is tripped or retried
OFF: While inverter is not tripped and not retried
6.19.3
147 FLRN Inversion of fault signal (output also at a
retry waiting)
Inversion of FLR
150 PTCA PTC input alarm signal ON: PTC thermal input value is f646 or more
OFF: PTC thermal input value is less than f646
6.29.16
151 PTCAN Inversion of PTC input alarm signal Inversion of PTCA
152 STO Safe torque off signal ON: Opening terminals between +SU and STO.
OFF: Shorting terminals between +SU and STO.
7.2.2
153 STON Inversion of safe torque off signal Inversion of STO
154 DISK Analog input break detection alarm ON: VIC terminal input value is f633 or less
OFF: VIC terminal input value is more than f633
6.29.14
155 DISKN Inversion of analog input break detection
alarm
Inversion of DISK
156 LI1 F terminal status ON: F terminal is ON status
OFF: F terminal is OFF status
7.2.2
157 LI1N Inversion of F terminal status Inversion of LI1
158 LI2 R terminal status ON: R terminal is ON status
OFF: R terminal is OFF status
159 LI2N Inversion of R terminal status Inversion of LI2
160 LTAF Cooling fan replacement alarm ON: Cooling fan reaches parts replacement time
OFF: Cooling fan does not reach parts replacement time
6.29.15
161 LTAFN Inversion of cooling fan replacement alarm Inversion of LTAF
162 NSA Number of starting alarm ON: Number of starting alarm is f648 or more
OFF: Number of starting alarm is less than f648
6.29.17
163 NSAN Inversion of number of starting alarm Inversion of NSA
166 DACC Acceleration operation in progress ON: Acceleration operation in progress
OFF: Other than those above
7.2.2
167 DACCN Inversion of acceleration operation in
progress
Inversion of DACC
168 DDEC Deceleration operation in progress ON: Deceleration operation in progress
OFF: Other than those above
169 DDECN Inversion of deceleration operation in
progress
Inversion of DDEC
170 DRUN Constant speed operation in progress ON: Constant speed operation in progress
OFF: Other than those above
171 DRUNN Inversion of constant speed operation in
progress
Inversion of DRUN
172 DDC DC braking in progress ON: DC braking in progress
OFF: Other than those above
6.12.1
173 DDCN Inversion of DC braking in progress Inversion of DDC
174 to 179 Factory specific coefficient - *1
180 IPU Integral input power pulse output signal ON: Integral input power unit reach
OFF: Other than those above
6.33.1
182 SMPA Shock monitoring pre-alarm signal ON: Current / torque value reach the shock monitoring
detection condition
OFF: Other than those above
6.28
183 SMPAN
Inversion of
shock monitoring pre-alarm
signal
Inversion of SMPA
222 to 253 Factory specific coefficient - *1
254 AOFF Always OFF Always OFF 7.2.2
255 AON Always ON Always ON
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
Note 1: As function No. that are not described in the table above are assigned "No function", output signal is always “OFF” at
even number, output signal is always “ON” at odd number.
To Next Page
