E6582175
C-6
3
(3) Coast stop
ssign parameters as described below in case of
Coast stop. Inverter will display off at Coast stop.
1) Assign "6 (ST)" to an input terminal. Set parameter
=. Open the ST-CC for coast stop(see the
status described on the right).
2) Assign "96 (FRR)" to an input terminal.
Coast stop is done by shorting FRR and CC.
Motor
speed
ON
OFF
ON
OFF
F-CC
ST-CC
Coast stop
