OPERATOR’S MANUAL
series Robot Controller
• EX. 232C
M O D E : E X . 2 32C/ CONT
L :
O : 1 00%
M : F REE
S : S TOP
R E SET
L D I S P W A T C H
• EX. ETHER (Standard for TS3000/Option for TSL3000)
M O D E : E X . E H T E R / C O N T
L :
O : 1 00%
M : F REE
S : S TOP
R E SET
L D I S P W A T C H
Descriptions on display
[1] MODE: Indicates the currently selected master mode and run mode.
EXT. SIG : External control signal mode
EX. 232C : Host mode (Control by host computer)
EX. ETHER : Host mode (Control by host computer)
CONT : Continuous operation
CYCLE : Cycle operation
[2] Right side on the 1st line: Displays active file name.
[3] L: No. of execution steps
[4] O: Speed override
[5] M: Machine status
FREE : Machine lock OFF status
[6] S: Execution status
RUN : A program is currently executed.
STOP RESET : A program is stopped in the initialize mode.
This is the same as the program reset.
STOP RETRY : A program is stopped in the restart mode.
It is restarted from the interrupted motion.
STE 80720
– 8-3 –
