TP-Link Touch P5 User Manual

Chapter 1 Get to Know About You Router
4
1. 2. 2. Menu Screen
Tap the icons to perform various functions of your Touch P5, such as Quick Setup, Mode
Selection, Parental Controls, etc.
1. 3. Button and Port Explanations
The router’s buttons and ports (view from left to right) are located on the back panel.
Item Description
Power Port For connecting the router to a power socket via the provided power adapter.
Power On/Off Button Press this button to power on or off the router.
USB 2.0 Port For connecting to a 2.0 USB storage device or a 2.0 USB printer.
USB 3.0 Port
It’s on the right front corner of your Touch P5.
For connecting to a 3.0 USB storage device or a 3.0 USB printer. It is also compatible
with USB 2.0 devices.
Internet Port
In router mode, for connecting to a DSL/Cable modem, or Ethernet.
In repeater mode, for connecting to an Ethernet-enabled device, working as an
Ethernet port.
In access point mode, for connecting to a host router or the Internet.
Ethernet Ports (1, 2, 3, 4) For connecting the router to your PC or other Ethernet-enabled devices.
Reset Button Press and hold the Reset button until the Touch P5 logo displays.
Antennas
Used for wireless operation and data transmit. Upright them for the best Wi-Fi
performance.

TP-Link Touch P5 Specifications

General

Color	black
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wep
Ports	rj-45
WAN Ports	1
Built In Modem	no
System Requirements	microsoft windows 98se, nt, 2000, xp, vista™ or windows 7, 8, 8.1, mac os, netware, unix or linux; internet explorer 11, firefox 12.0, chrome 20.0, safari 4.0, or other java-enabled browser

Weight and Dimensions

Height	2.1 inches
Width	11.2 inches
Net Weight	2.98 pounds
