TP-Link Touch P5 User Manual

Chapter 3 Configure Touch P5 as a Repeater
69
5. Tap Default Gateway to enter the gateway in dotted decimal notation . It should be
in the same subnet as the IP address.
6. Tap Save.
3. 7. DHCP Server
The DHCP Server app can configure your Touch P5 to act as a DHCP (Dynamic Host
Configuration Protocol) server to assign IP addresses to its clients and view client
information from the client list. To use the DHCP server function of your Touch P5, you
must configure all computers on the LAN as Obtain an IP Address automatically. You
can also manually reserve an IP address for a client that is connected to your Touch P5.
Once reserved, the IP address will only be assigned to the client by the DHCP server.
1. On the menu screen, tap the DHCP Server icon to start it.
2. Configure the DHCP settings as needed.
¾ To set DHCP server of your Touch P5:
1 ) Select DHCP Server.

TP-Link Touch P5 Specifications

General

Color	black
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	3
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wep
Ports	rj-45
WAN Ports	1
Built In Modem	no
System Requirements	microsoft windows 98se, nt, 2000, xp, vista™ or windows 7, 8, 8.1, mac os, netware, unix or linux; internet explorer 11, firefox 12.0, chrome 20.0, safari 4.0, or other java-enabled browser

Weight and Dimensions

Height	2.1 inches
Width	11.2 inches
Net Weight	2.98 pounds
