4. Safety Instruction
1. Read Instruction:
All the safety and operation instructions should be read before the Bonder is operated.
2. Do not remove Safety Instruction from User Manual
3. When carrying the Bonder around, do not subject the Bonder
to heavy shock or vibration. Two people needed for Transportation
4. The Bonder should be installed on a solid horizontal base
5. Power Sources: The Bonder be operated only from the power source indicated on the
marking label.
The Bonder is equipped with a three-wire grounding plug
Do not defeat the safety purpose of the grounding plug.
Make sure grounding cable is connected
6. Protection Circuitry: The Bonder is equipped with two power line fuses at the power
connector and one fuses inside behind the power connector SI 5 A ,
7. The Cover should only be opened after powering down the machine
and removing the power cord from the wall outlet
8. Laser Spot Light, Attention!
Don’t stare into the beam. Direct viewing into the Beam can cause permanent eye
damage. Please note regulations according to EN 60825-1 and VBG 93 Laser class 2, P
= 1mW
9. Hot machine parts:
The maximum temperature of heated Work holder is 250°C.
Allowing parts cooling down before replacing Heated Work holder,
illumination lamps or any other hot machine part.
10. EFO ( Electronic Flam Off) Only If Bonder is equip with EFO System
Do not touch the electrode or the wire during bonding or when manually firing the EFO.
11. The System produces a High Voltage spark. The potential shock hazard is not usually
considered life threatening. However, TPT recommends that those persons with
abnormal heart conditions or artificial heart stimulation devices (e.g. pacemakers) should
not be permitted to operate or service this Bonder
12. Bonding Tools have sharp edges, beware of touching them.
13. All Service and maintenance should be performed by trained, authorized personnel.
4.1. Power-On
Before plugging the power cord into the A. C. power source, check the label located on the rear of the HB
Bonder . lf the label does not agree with the available A. C. power, do not plug in the power cord. Check the A.
C. power socket for correct wiring.
POWER ON/OFF Switch is on back left side,
TFT Display light on indicate that POWER is on.
