TPT Wirebonder www.tpt.de Page 29 of 53 September 2016
26. Option H80 "Pick and Place"
Switch Bond Mode to "Pick and Place" and connect Vacuum Pump Tube
27. Epoxy Stamping Pot
adjusting Blade height
Loosen set screw Turn screw to adjust Blade height
360° turn is 500µm
180° turn is 250µm
90° turn is 125µm
Clean
Loosen set screw remove cam to clean
It is possible to clean the aluminum pot with acetone and other solvents.
It is also possible to remove the pot complete for cleaning.
