45. Heater Stage
H26
hot plate: 60mm diameter
temperatur range: until 250°C
height adjustable from 65mm to 80mm
dimesion: 75 mm diameter
H29
hot plate: 90mm diameter
temperatur range: 250°C
height adjustable
H21-250
heating plate 100 x 100 mm
temperature range until 250°C
height adjustable from 65 to 80 mm
dimension 125x125mm height 65-80mm
H22-250 hot plate 100 x 150 mm
temperature range until 250°C
height adjustable from 65 to 80 mm
