7.2.3.1 Attribute 0x05, Status
Status returns the summary status of the measuring system:
Bit
Called
Definition
0
Owned
Under EtherNet/IP™ without meaning
1
-
0, reserved
2
Configured
TRUE: Indicates the application of the device has been
configured to do something different than the
“out–of–box” default.
3
-
0, reserved
4-7
Extended
Device Status
see table below
8
Minor
Recoverable Fault
TRUE: Indicates the device detected a problem with
itself, which is thought to be recoverable. The problem
does not cause the device to go into one of the faulted
states. See Behavior section.
9
Minor
Unrecoverable
Fault
TRUE: Indicates the device detected a problem with
itself, which is thought to be unrecoverable. The
problem does not cause the device to go into one of the
faulted states. See Behavior section.
10
Major
Recoverable Fault
TRUE: Indicates the device detected a problem with
itself, which caused the device to go into the “Major
Recoverable Fault” state. See Behavior section.
11
Major
Unrecoverable
Fault
TRUE: Indicates the device detected a problem with
itself, which caused the device to go into the “Major
Unrecoverable Fault” state. See Behavior section.
12-15
-
0, reserved
Bit definitions for extended device status field
Bits 4-7
Description
0000
Self-Testing or unknown
0001
Firmware update in progress
0010
At least one faulted I/O connection
0011
No I/O connections established
0100
Non volatile configuration bad
0101
Major Fault – either bit 10 or bit 11 is true (1)
0110
At least one I/O connection in run mode
0111
At least one I/O connection established, all in idle mode
1000
0, reserved
1001
0, reserved
1010-1111
0, not supported
