7.6.3.5.1 Attribute 0x65, Total Measuring Range
Total Measuring Range defines the total number of steps of the measuring
system before the measuring system restarts at zero.
CEx-65: 33 554 432 steps (25 bit)
COx-65: 68 719 476 736 steps (36 bit)
The actual upper limit for the measurement length to be entered in steps is dependent
on the measuring system version and can be calculated with the formula below. As
the value "0" is already counted as a step, the end value = measurement length in
steps - 1.
Total measuring range = Steps per revolution * Number of revolutions
Formula 1: General Scaling parameter
To calculate, the parameters steps/rev. and the number of revolutions can be read
on the measuring system nameplate.
Connection path, Packed EPATH with 8 bit class
So that this attribute is accepted and saved permanently, 0x70 Accept Parameter
must be performed.
