7.6.3.1 Attribute 0x02, Attribute List
Attribute List liefert die unterstützten Attribute des Position Sensor Object
als HEX-Wert zurück:
ARRAY (USINT), nur lesen
Attr.-ID
Name
0x02
Attribute List
0x0B
Position Sensor Type
0x0C
Direction Counting Toggle
0x64
Position Value
0x65
Total Measuring Range
0x66
Number of Revolutions - numerator
0x67
Number of Revolutions - divisor
0x68
Preset Value
0x70
Accept Parameter
Verbindungspfad, Packed EPATH mit 8 Bit Klasse
0x20
0x23
0x24
0x01
0x30
0x02
Logical Type
= Class
Class #23
Logical Type
= Instance
Instance #1
Logical Type
=Attr.-ID
Attr.-ID #2
7.6.3.2 Attribute 0x0B, Position Sensor Type
Position Sensor Type liefert den Gerätetyp zurück:
UINT, nur lesen
Wert
Definition
01
Absoluter Single-Turn Encoder
02
Absoluter Multi-Turn Encoder
04
Inkremental Encoder
06
Inkremental Linear Encoder
08
Absoluter Linear Encoder
10
Multi-Sensor Encoder Interface
Verbindungspfad, Packed EPATH mit 8 Bit Klasse
0x20
0x23
0x24
0x01
0x30
0x0B
Logical Type
= Class
Class #23
Logical Type
= Instance
Instance #1
Logical Type
=Attr.-ID
Attr.-ID #11
