7.8.3.4 Attribute 0x04, Physical Link Object
This attribute identifies the object associated with the underlying physical
communications interface. There are two components to the attribute:
● Path Size in UINTs
● Path
The Path contains a Logical Segment, type Class, and a Logical Segment, type
Instance that identifies the physical link object. The physical link object itself typically
maintains link-specific counters as well as any link specific configuration attributes.
Because the CIP™ port associated with the TCP/IP Interface Object has an
Ethernet physical layer, this attribute points to an instance of the Ethernet Link
Object, class code = 0xF6.
Path
Description
[20] [F6] [24] [01]
[20]: 8 Bit Class Segment Type
[F6]: Ethernet Link Object Class
[24]: 8 Bit Instance Segment Type
[01]: Instance 1
7.8.3.5 Attribute 0x05, Interface Configuration
The Interface Configuration attribute contains the configuration parameters
required to operate the measuring system as a TCP/IP node. In order to prevent
incomplete or incompatible configuration, the parameters making up the Interface
Configuration attribute cannot be set individually. To modify the Interface
Configuration attribute, the user should first Get the Interface Configuration
Attribute, change the desired parameters then set the attribute.
Name
Description
IP address
Sets the device’s IP address
Network mask
Sets the device’s Subnet mask
Gateway address
Sets the device’s default Gateway
Name server
0, not supported
Name server 2
0, not supported
Domain name
0, not supported
