11 Appendix
11.1 Elementary Data types
Data types
Code
Description
BOOL
0xC1
Logical Boolean with values TRUE and FALSE
SINT
0xC2
Signed 8 Bit Integer
INT
0xC3
Signed 16 Bit Integer
DINT
0xC4
Signed 32 Bit Integer
LINT
0xC5
Signed 64 Bit Integer
USINT
0xC6
Unsigned 8 Bit Integer
UINT
0xC7
Unsigned 16 Bit Integer
UDINT
0xC8
Unsigned 32Bit Integer
ULINT
0xC9
Unsigned 64 Bit Integer
REAL
0xCA
32 Bit Floating Point
LREAL
0xCB
64 Bit Floating Point
STRING
0xD0
Character String, 1 Byte/Character
BYTE
0xD1
Bit String, 8 Bit
WORD
0xD2
Bit String, 16 Bit
DWORD
0xD3
Bit String, 32 Bit
LWORD
0xD4
Bit String, 64 Bit
SHORT_STRING
0xDA
Character String, 1 Byte/Character, 1 Byte length indicator
EPATH
0xDC
CIP Path Segment
STRINGI
0xDE
International Character String
