5.2.2 Network Status LED
LED Status
Cause
Description
OFF
Not powered,
no IP address
Device is not powered
or does not have an IP address.
1 Hz
No connections
Device has no established connections,
but has obtained an IP address.
ON
Connected
The device has at least one established
connection, e.g. to the Message Router.
1 Hz green/red
Self-test
Valid, while the device is performing its power
up testing.
5.2.3 Error LED
LED Status
Cause
Description
1 Hz
Connection Timeout
One or more of the connections in which this
device is the target has timed out. This state
is left only if all timed out connections are re-
established or if the device is reset.
ON
Duplicate IP
The device has detected that its IP address is
already in use
1 Hz green/red
Self-test
Valid, while the device is performing its power
up testing.
