7.8 Object 0xF5, TCP/IP Interface
The TCP/IP Interface Object provides the mechanism to configure the TCP/IP
network interface and contains the device’s IP Address, Network Mask and Gateway
Address for example.
The measuring system supports exactly one instance of the TCP/IP Interface Object
for each TCP/IP capable communications interface on the module.
7.8.1 Common Services
Service Code
Service Name
Description
0x01
Get_Attributes_All
Returns the contents of all attributes.
The order corresponds to the Attr.-ID.
According to the data type the Low part
is written first.
0x0E
Get_Attribute_Single
Returns the contents of the specified
attribute.
0x10
Set_Attribute_Single
Modifies the contents of the specified
attribute.
7.8.2 Class Attributes
No.
Access
Name
Data type
Attribute Description
Default
1
Get
Revision
UINT
Revision of this object
0x00 01
2
Get
Max Instance
UINT
Maximum instance number of an
object currently created in this class
level of the device.
0x00 01
3
Get
Number of
Instances
UINT
Number of object instances
currently created at this class level
of the device.
0x00 01
4
-
-
-
not implemented
-
5
-
-
-
not implemented
-
6
Get
Maximum
ID Number
Class
Attributes
UINT
The attribute ID number of the last
class attribute of the class definition
implemented in the device.
0x00 07
7
Get
Maximum
ID Number
Instance
Attributes
UINT
The attribute ID number of the last
instance attribute of the class
definition implemented in the
device.
0x00 06
Table 24: TCP/IP Interface, Overview of the class attributes
