7.2.5 Object-specific Status Codes
HEX notation
General
Status Code
Extended
Status Code
Name
Description
00 – CF
General Codes
see page 151
00 – EE
Reserved Extended Status Codes
F0 - FE
Vendor Specific
Vendor specific Extended Codes
FF
Used with all General Codes when
required and no other Extended
Code is assigned.
D0
Hardware
Diagnostic
Device Self-Testing and Hardware
Diagnostic Conditions
00
reserved
01
Checksum (or CRC) error – Code
space/ROM – Boot section
02
Checksum (or CRC) error – Code
space/ROM – Application section
03
Checksum (or CRC) error – NV
(FLASH/EEPROM) memory
04
Invalid non-volatile (NV) memory –
Configuration bad
05
Invalid non-volatile (NV) memory –
No configuration established
06
RAM memory bad – The RAM
memory in the device was
determined to be experiencing
inoperative cells
07
ROM/Flash Memory bad
08
Flash/EEPROM (NV) Memory Bad
09
Interconnect wiring error / signal
path problem
0A
Power problem – Over current
0B
Power problem – Over voltage
0C
Power problem – Under voltage
0D
Internal Sensor problem
0E
System Clock Fault
0F
Hardware configuration does not
match NV configuration
10
Watchdog Disabled/Idle
11
Watchdog Timer Expired
12
Device over temperature
13
Ambient temperature outside of
operating limits
14 – EF
reserved

