7.1 Overview of available classes
Object Classes
Purpose
Access
Page
0x01: Identity Object
Contains all device specific data, such as
Vendor ID, Device type, Device status etc.
Get
105
0x02: Message Router Object
Contains the measuring system’s supported
class codes and the max. number of
connections.
Get
112
0x04: Assembly Object
Returns the position value of the measuring
system.
Get
114
0x06: Connection Manager Object
Contains connection specific attributes for
triggering, transport, connection type etc.
Get
117
0x23: Position Sensor Object
Contains all attributes for programming the
measuring system parameter, such as
scaling and count direction.
Set/Get
119
0xF4: Port Object
Contains the available Ports, Port name and
Node address on the port.
Get
130
0xF5: TCP/IP Interface Object
Contains all attributes for the configuration
of the TCP/IP network interface such as IP
address, Subnet mask and Gateway.
Defines how the measuring system gets
these parameters: FLASH, DHCP or
hardware switch.
Set/Get
133
0xF6: Ethernet Link Object
Contains connection specific attributes,
such as Transmission rate, Interface status
and the MAC-Address.
Get
139
Table 8: Overview of available classes
