Parameterization and configuration
 TR-Electronic GmbH 2004, All Rights Reserved Printed in the Federal Republic of Germany
Page 86 of 112 TR - ECE - BA - DGB - 0036 - 16 11/05/2018
Continuation
11-12 Revolutions denominator Unsigned16
Number of revolutions as fraction
Default = 1 (denominator)
96
13
Code SSI-Interface
Unsigned8
not supported
-
14
Code PROFIBUS-
Interface
Unsigned8 Bit 1-0
00: Gray
01: Binary [x]
10: Shifted Gray
98
15-18
Preset 1
Unsigned32
not supported
-
19-22
Preset 2
Unsigned32
not supported
-
23-26 Lower limit switch Unsigned32
Position value for lower limit switch
Default = 0
98
27-30 Upper limit switch Unsigned32
Position value for upper limit switch
Default = 4096
98
31
Data bits SSI-Interface
Unsigned8
not supported
-
32 Velocity Unsigned8
Resolution of the speed output
Default = 1 (1 Digit = 1 revol./min)
98
