TK 61009-12-OP-EN
23
Getting Started
Factory Settings
Here are the settings of the TouchLog as programmed during the production
process.
The default values for the parameters of the user menu – (See “User
Menu,” p. 32 for more details) – are as follows:
Table 1. Factory Settings
Recording mode ON, meaning permanent logging when the device is powered
Company reference Comp_ref1, Comp_ref2, Comp_ref3
Trailer ID Tr. 12345
Language English
Zone selection 1+2
Input setting
• Input 1: NTC Temperature sensor; Label: front; Zone: 1
• Input 2: NTC Temperature sensor; Label: rear; Zone: 2
Logging interval
5 minutes
Temperature unit
°C
Backlight timer
Timed 30 sec
Backlight
50%
Contrast 50%
Daylight saving
Auto
Print media selection USB Flash Drive
File format
.pdf
Wintrac interface USB enabled
The default values for the parameters of the service menu – (See “Service
Menu,” p. 37) – are as follows:
1. Temperature range for graph printing: -30°C to +30°C
2. Graph scale: 3 hours per cm
3. Date and Time settings dd/mm/yyyy, hh:mm:ss
