TK 61009-12-OP-EN
41
files have been copied into the external flash memory, the following
image will appear.
10. Once the process is complete, the TouchLog will be restarted, and the
boot-loader will start to copy the firmware from the external flash into
the MCU flash.
The error message that can appear in this menu are as follow:
Error message
Description
NO DEVICE
No USB flash Drive recognised
NO FILE
No files with .bin or .glo are present into the flash drive
*******************
The File name is too long (the file name plus extension must
be less than 19 character)
Wintrac Interface via USB
This menu enables to establish the connection to Wintrac (Thermo
King software for temperature and refrigeration unit analysis) by
detecting the USB cable connected (spn 420970) from the
TouchLog to the PC. The default parameter (Modbus) entered
should allow to communicate to Wintrac, if necessary the user has
the possibility to manually change the protocol and the address.
ON/AUTO/OFF Data Logging
This function enables to change the recording mode from ON to
Auto or OFF in order to save the power source when the unit is not
running. The following table shows the status of alarms and
recordings with regards to the ignition key input.
AAddvvaanncceedd OOppeerraattiioonn
