52
TK 61009-12-OP-EN
Once setup, a USB Flash drive while connected to the mini USB port via the
provided cable interface (spn 420969) will be automatically detected. The
TouchLog is compatible with most of the commonly used USB Flash Drive.
In the user menu via the Icon - Media selection for printing, the
user select between the printer logo and the USB logo.
NNoottee:: By default, it’s the printer setup that is configured.
Then the second selection is the file format between .pdf and txt output.
When the data is transferring, the display is showing this view.
After this setup, the user will navigate through the print menu as he will do
to print a physical ticket, with the same option available. See “Print
Menu,” p. 30.
NNoottee:: Currently the graph printing option is not available when exporting the
data to a USB flash drive.
WWiinnttrraacc CCoommmmuunniiccaattiioonn aanndd DDaattaa EExxppoorrtt
