Trane CVHH - Page 100

Waterbox Removal and Installation
100 CVHH-SVX001A-EN
10H
Heat Recovery Condenser,
1034.2 kPa (150 psi)
917
(2022)
21.8
(0.858)
NA NA NA NA NA NA NA NA
13H
Heat Recovery Condenser,
1034.2 kPa (150 psi)
1106
(2439)
21.8
(0.858)
NA NA NA NA NA NA NA NA
20H
Heat Recovery Condenser,
1034.2 kPa (150 psi)
1247
(2750)
21.8
(0.858)
NA NA NA NA NA NA NA NA
22H
Heat Recovery Condenser,
1034.2 kPa (150 psi)
1747
(3853)
21.8
(0.858)
NA NA NA NA NA NA NA NA
Table 24. CVHH waterbox weights (continued)
Shell
Size Description
Non- Marine
Plate
Non-Marine
Dom e
Marine Plate
Cover
Marine Dom e
Cover
Marine
W aterbox
W eight
kg ( lb)
Lifting
Hole
mm
( in.)
W eight
kg ( lb)
Lifting
Hole
mm
( in.)
W eight
kg ( lb)
Lifting
Hole
mm
( in.)
W eight
kg ( lb)
Lifting
Hole
mm
( in.)
W eight
kg ( lb)
Lifting
Hole
mm
( in.)
