Electrical Requirements
48 CVHH-SVX001A-EN
Trane-Supplied Remote Starter Wiring
Table 13. Standard field power wiring requirements
Pow er Supply W iring
to Starter Panel
Starter Panel
Terminals
3-Phase Line Voltage L1, L2, L3, and GROUND
(a)
Starter to Motor Pow er W iring Starter Motor
Rem ote Starter to Chiller Motor Junction Box T1 through T6 T1 through T6
Pow er Su pply W iring t o Unit- Mount ed
Control Pow er Transformer
( CPTR Optional)
Control Pow er
Transformer Term inals
3-Phase Line Voltage
(b)
6Q1-1,3,5
Ground CPTR panel GND
Starter to Control Panel
12 0 Vac Control W iring
Starter Panel
Terminals
Unit Control Panel
Term inations
120 Vac Pow er Supply ( fr om st art er t o cont rol
pan el)
2X8-1, 2X8-2
2X8-G (Ground)
1X1-1, 1X1-12
1X1-G (Ground)
High Pressure Cutout to Starter 2X8-4 1X1-4
1F1 Circuit Breaker to Starter 2X8-3 1X1-2
Oil Pum p Interlock 2X8-7, 2X8-8 1X1-10, 1X1-21
LV starter Oil/Refrigerant pum p start 2X8-24 1X1-21
MV starter Oil/ Refrigerant pump start 2X8-14 1X1-21
Oil/ Refrigerant pump neutral 2X8-25 1X1-16
Starter to Oil/ Refrigerant Pump
Junction Box
Starter Panel
Terminals
Oil/ Refrigerant
Pump Junction Box
Low Voltage 3-Phase Pump Power 2X8-21, 2X8-22, 2X8-23 4X4-1, 4X4-2, 4X4-3
Medium Voltage 1-Phase Pump Power 2X8-12, 2X8-13 4X4-1, 4X4-4
Low Voltage Circuits
less than 3 0 Vac
Starter Panel
Terminals
Unit Control Panel
Term inations
Standard Circuits
Inter Processor Communications (I PC)
Remote Mounted
(c)
2K32-J3-3-4, or
2X1-12 to 13 if present (do not
ground shield at starter)
1T2-J53-4
Shield ground at
1X1-G (GND) only.
2 wire with ground
Comm link
Notes:
1 . All wiring to be in accordance with National Electrical Code and any local codes.
2 . Auxiliary equipment must be powered from other sources as the chiller control panel power supplies are sized for the chiller loads only.
(a) Ground lug for a unit-m ounted solid state starter or wye-delta starter is sized to accept 14 AWG solid to 8 AWG strand wire. For AWG/ MCM equivalents
in m m
2
, refer to
Table 12, p. 47. If local codes require different lug size, it must be field-supplied and -installed.
(b) Refer to submittal and ship-with wiring schem atics for voltage requirements.
(c) Must be separated from 120 Vac and higher wiring.
