Unit Components
Note: The control panel side of the unit is always
designated as the front side of the unit.
Figure 3. Typical Simplex CVHH CenTraVac chiller
1. Suction Elbow
2. Compressor
3. Terminal Box
4. Control Panel
5. Condenser
6. Motor Housing
7. Economizer
8. Oil Tank Assembly
9. Purge
10. Evaporator
11. Display Panel
1
2
3
4
0
-
0
6
7
5
9
8
