Trane CVHH - Storage Requirements

Pre-Installation
CVHH-SVX001A-EN 13
Storage Requirements
“CenTraVac™ Installation
Com pletion Check Sheet
and Request for Trane
Service”
(CTV-ADF001-EN; refer to
“ For m s and Check Sheet s,”
p. 102
)
• To be completed by installing contractor prior to
contacting Trane for start-up
Chiller start-up
com m issioning
(a)
• Trane, or an agent of Trane
specifically authorized to
perform start-up of Trane
®
products
(a) Start-up must be performed by Trane or an agent of Trane specifically authorized to perform start-up and warranty of Trane
®
products. Contractor shall
provide Trane (or an agent of Trane specifically authorized to perform start-up) with notice of the scheduled start-up at least two weeks prior to the
scheduled start-up.
Type of
Requirem ent
Trane Supplied
Trane I nstalled
Trane Supplied
Field I nstalled
Field Supplied
Field I nstalled
NOTICE:
Insulation Damage!
Do not expose unit to direct sunlight as it could result
in damage to factory-installed insulation.
Less than 1 m onth 1– 6 m onths Greater than 6 m onths
Location requirements:
• solid foundation
• vibration free
• dry
• tem perature range -40°C to 70°C
(-40°F to 158°F)
Location requirements:
• solid foundation
• vibration free
• dry
• temperature range -40°C to 70°C
(-40°F to 158°F)
Location requirements:
• solid foundation
• vibration free
• dry
• temperature range -40°C to 70°C
(-40°F to 158°F)
• Do not remove any plastic coverings • Do not remove any plastic coverings • Do not remove any plastic coverings
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufactures storage requirements
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufactures storage requirements
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufactures storage requirements
• Verify dry nitrogen pressure using gauge
located on the evaporator shell reads
20.7 to 34.5 kPag (3 to 5 psig)
• Notify the local Trane office if charge has
escaped
• Verify dry nitrogen pressure using gauge
located on the evaporator shell reads
20.7 to 34.5 kPag (3 to 5 psig)
• Notify the local Trane office if charge has
escaped
• Verify dry nitrogen pressure using gauge located
on the evaporator shell reads 20.7 to 34.5 kPag
(3 to 5 psig)
• Notify the local Trane office if charge has escaped
• Do not operate purge unit • Do not operate purge unit • Do not operate purge unit
• Verify waterbox and tube bundles are
clean and dry
• Verify waterbox and tube bundles are clean and
dry
• Conduct an oil analysis and verify no oil
breakdown
(a)
• Repeat yearly
• Replace oil if breakdown has occurred
• If no oil analysis program has been followed,
replace oil prior to start up
Note: Chillers stored 5 years or longer should be inspected every 5 years by a qualified service organization for leaks.
(a) If protective plastic coverings need to be removed for access and/ or service, contact your local Trane office.
