Unit Clearances and Weights
16 CVHH-SVX001A-EN
General Weights
The unit weight information provided in
Ta b l e 2 should
be used for general information purposes only. Trane
does not recommend using this weight information for
considerations relative to chiller handling. The large
number of variances between chiller selections drives
variances in chiller weights that are not recognized in
this table. For specific weights for your chiller, refer to
your submittal package.
The values in
Tab l e 2 representing chiller weights include
the following:
• TECU 0.028-in. (0.71 mm) tube wall.
• 1034.2 kPag (150 psig) non-marine waterboxes.
• Operating weights include the largest possible
refrigerant charge.
• Chillers with starter weights include the weight of
the heaviest possible starter.
• Heaviest possible bundle and heaviest possible
motor combination for the application family
chiller.
The values in
Tab l e 2 representing chiller weights do NOT
include the following options:
• INDP (Industrial Control Panel) option—add 23 kg
(50 lb)
• CPTR (Control Panel Transformer) option—add
127 kg (280 lb)
• SMP (Supplem ental M otor Protection) option—add
230 kg (500 lb)
Table 1. Clearance requirements
(a)
Shell Combo
ABCDE
cm in. cm in. cm in. cm in. cm in.
100M/ 100M 213 84 422 166 1057 416 30 12 310 122
100M/10HM 213 84 422 166 1057 416 79 31 300 118
100L/ 100L 213 84 422 186 1161 457 30 12 310 122
130M/ 130M 224 88 422 166 1067 420 74 29 277 109
130M/13HM 224 88 422 166 1067 420 79 31 312 123
160M/ 200M 244 96 422 166 1087 428 94 37 285 112
160M/20HM 244 96 422 166 1087 428 91 36 325 128
200L/ 200L 272 107 472 186 1217 479 86 34 282 111
200L/ 20HL 272 107 472 186 1217 479 94 37 333 131
200L/ 220L 272 107 472 186 1219 480 94 37 305 120
220L/ 220L 305 120 472 186 1252 493 97 38 300 118
220L/ 22HL 305 120 472 186 1250 492 107 42 363 143
(a) All dimensions are approximate; refer to the unit submittal package for exact dimensions for your unit.
Table 2. Unit weights
W eight w ithout Starters W eight w ith Starters
Operating Shipping Operating Shipping
MODEL NTON Hz EVSZ CDSZ kg lb kg lb kg lb kg lb
CVHH 900–1200 60 100M 100M 19748 43538 17218 37959 20044 44190 17514 38611
900–1200 60 100L 100L 20562 45331 17802 39246 20858 45983 18097 39898
900–1200 60 100M 10HM 21946 48382 19226 42386 22241 49034 19522 43038
900–1200 60 130M 130M 22193 48927 19019 41929 22489 49579 19314 42581
900–1200 60 130M 13HM 24873 54836 21522 47447 25169 55488 21817 48099
900–1200 60 160M 200M 25523 56269 21503 47405 25819 56921 21798 48057
900–1200 60 160M 20HM 28516 62868 24353 53690 28812 63520 24649 54342
900–1200 60 200L 220L 28443 62707 23780 52425 28739 63359 24075 53077
900–1200 60 220L 220L 30193 66564 25080 55291 30489 67216 25375 55943
1700–1500 60 200L 200L 27480 60583 23188 51120 27776 61235 23483 51772
1700–1500 60 200L 20HL 30683 67644 26248 57867 30979 68296 26544 58519
1700–1500 60 220L 220L 30588 67434 25474 56161 30883 68086 25770 56813
1700–1500 60 220L 22HL 34497 76053 29234 64451 34793 76705 29530 65103
1550 50 200L 200L 28456 62735 24164 53272 28752 63387 24459 53924
1550 50 200L 20HL 31659 69796 27224 60019 31955 70448 27520 60671
1550 50 220L 220L 31564 69586 26450 58313 31859 70238 26746 58965
1550 50 220L 22HL 35473 78205 30211 66603 35769 78857 30506 67255
