[1005] Readout Transmit Error
Counter
View the number of CAN control transmission errors since the last pow-
er-up.
[1006] Readout Receive Error
Counter
View the number of CAN control receipt errors since the last power-up.
[1007] Readout Bus Off Counter View the number of Bus Off events since the last power-up.
[1013] Warning Parameter View a DeviceNet-specific warning word. One separate bit is assigned to
every warning.
[1115] LON Warning Word Shows the LON-specific warnings.
[1117] XIF Revision Shows the version of the external interface file of the Neuron C chip on
the LON option.
[1118] LonWorks Revision Shows the software version of the application program of the Neuron C
chip on the LON option.
[1501] Running Hours View the number of running hours of the motor.
[1502] kWh Counter View the mains power consumption in kWh.
[1600] Control Word View the Control Word sent from the frequency converter via the serial
communication port in hex code.
[1601] Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and
slow-down) in selected unit.
[1602] * Reference [%] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and
slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value [%] View the two-byte word sent with the Status word to the bus Master
reporting the Main Actual Value.
[1609] Custom Readout View the user-defined readouts as defined in par.0-30
Custom Readout
Unit, par.0-31 Custom Readout Min Value and par.0-32 Custom Readout
Max Value.
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, i.e. the output frequency from the frequency converter
in Hz.
[1614] Motor Current Phase current of the motor measured as effective value.
[1615] Frequency [%] Motor frequency, i.e. the output frequency from the frequency converter
in percent.
[1616] Torque [Nm] Present motor load as a percentage of the rated motor torque.
[1617] Speed [RPM] Motor speed reference. Actual speed will depend on slip compensation
being used (compensation set in par.1-62
Slip Compensation). If not
used, actual speed will be the value read in the display minus motor slip.
[1618] Motor Thermal Thermal load on the motor, calculated by the ETR function. See also pa-
rameter group 1-9* Motor Temperature.
[1622] Torque [%] Shows the actual torque produced, in percentage.
[1630] DC Link Voltage Intermediate circuit voltage in the frequency converter.
Parameter Description
TR200 Programming Guide 45
