Page #45 background image
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 N/A* [0 - 255 N/A] View a list of all the set-ups linked by means of par.0-12
This Set-up
Linked to. The parameter has one index for each parameter set-up. The
parameter value displayed for each index represents which setups are
linked to that parameter setup.
Index
keypad value
0 {0}
1{1,2}
2 {1,2}
3{3}
4 {4}
Table 4. 2: Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Prog. Set-ups / Channel
Range: Function:
0 N/A* [-2147483648 -
2147483647 N/A]
View the setting of par.0-11
Programming Set-up for each of the four
different communication channels. When the number is displayed in
hex, as it is in the keypad, each number represents one channel.
Numbers 1-4 represent a set-up number; ‘F’ means factory setting; and
‘A’ means active set-up. The channels are, from right to left: keypad, FC
bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that the FC bus selected Set-
up 2 in par.0-11
Programming Set-up, the keypad selected Set-up 1 and
all others used the active set-up.
0-2* keypad Display
Define the variables displayed in the Graphical Local Control Panel.
Note
Please refer to par.0-37
Display Text 1, par.0-38 Display Text 2 and par.0-39 Display Text 3 for information on
how to write display texts.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, left position.
[0] * None No display value selected
[37] Display Text 1 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[38] Display Text 2 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[39] Display Text 3 Enables an individual text string to be written, for display in the keypad
or to be read via serial communication.
[89] Date and Time Readout Displays the current date and time.
[953] Profibus Warning Word Displays Profibus communication warnings.
Parameter Description
44 TR200 Programming Guide
