Unit Type Speed Relation
Dimensionless Linear
Speed
Flow, volume
Flow, mass
Velocity
Length
Temperature
Pressure Quadratic
Power Cubic
0-30 Custom Readout Unit
Option: Function:
Program a value to be shown in the display of the keypad. The value has
a linear, squared or cubed relation to speed. This relation depends on
the unit selected (see table above). The actual calculated value can be
read in par.16-09
Custom Readout, and/or shown in the display be se-
lecting Custom Readout [16-09] in par.0-20
Display Line 1.1 Small to par.
0-24
Display Line 3 Large.
[0]
[1] * %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
Parameter Description
50 TR200 Programming Guide
