Triumph Rocket 3 R User Manual

Maintenance
152
Battery Disposal
Should the battery ever require
replacement, the original battery must
be handed to a recycling agent who
will make sure that the dangerous
substances from which the battery
is manufactured do not pollute the
environment.
Battery Maintenance
Warning
Battery acid is corrosive and
poisonous and will cause damage to
unprotected skin.
Never swallow battery acid or allow it
to come into contact with the skin.
To prevent injury, always wear eye
and skin protection when handling the
battery.
The battery is a sealed type and does
not require any maintenance other
than checking the voltage and routine
recharging when required, such as
during storage.
Clean the battery using a clean,
dry cloth. Make sure that the cable
connections are clean.
It is not possible to adjust the battery
acid level in the battery; the sealing
strip must not be removed.
Battery Discharge
Caution
The charge level in the battery must
be maintained to maximize battery life.
Failure to maintain the battery charge
level could cause serious internal
damage to the battery.
Under normal conditions, the motorcycle
charging system will keep the
battery fully charged. However, if the
motorcycle is unused, the battery will
gradually discharge due to a normal
process called self discharge; the clock,
Engine Control Module (ECM) memory,
high ambient temperatures, or the
addition of electrical security systems
or other electrical accessories will all
increase this rate of battery discharge.
Disconnecting the battery from the
motorcycle during storage will reduce
the rate of discharge.
Battery Discharge During Storage
and Infrequent Use of the
Motorcycle
During storage or infrequent use of the
motorcycle, inspect the battery voltage
weekly using a multimeter. Follow the
manufacturer’s instructions supplied
with the meter.
Should the battery voltage fall below
12.7 Volts, the battery should be
charged.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
