Triumph Rocket 3 R User Manual

General Information
76
Tire Pressure Sensor Serial Number
The serial number for the tire pressure
sensor is printed on a label attached
to the sensor. This number may be
required by your authorized Triumph
dealer for service or diagnostics.
When the tire pressure monitoring
system is being installed to the
motorcycle, make sure that your
authorized Triumph dealer records the
serial numbers of the front and rear tire
pressure sensors in the spaces provided
below.
Front Tire Pressure Sensor
Rear Tire Pressure Sensor
TPMS System Display
The tire pressure warning
light works in conjunction
with the Tire Pressure
Monitoring System (TPMS).
The warning light will illuminate when
the front or rear tire pressure is below
the recommended pressure. It will not
illuminate if the tire is over inflated.
When the warning light is illuminated,
the TPMS symbol indicating which is
the deflated tire and its pressure will
automatically be shown in the tire
pressure display.
A
15:53
FRONT
REAR
1.9
2.9
bar
bar
Front Tyre
Low
TPMS
2
2
1
4
3
1. TPMS warning light
2. Front tire pressure indicator
3. Rear tire pressure indicator
4. TPMS information tray message
The tire pressure at which the warning
light illuminates is temperature
compensated to 68°F (20°C) but the
numeric pressure display associated
with it is not. Even if the numeric display
seems at or close to the standard tire
pressure when the warning light is on,
a low tire pressure is indicated and a
puncture is the most likely cause.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
