Triumph Rocket 3 R User Manual

General Information
75
Tire Pressure Monitoring
System (TPMS) (if equipped)
Warning
The daily check of tire pressures
must not be excluded because of
the installation of the Tire Pressure
Monitoring System (TPMS).
Check the tire pressure when the
tires are cold using an accurate tire
pressure gage, see the Tire section for
more information.
Use of the TPMS system to set
inflation pressures may lead to
incorrect tire pressures leading to loss
of motorcycle control and an accident.
Note
The Tire Pressure Monitoring System
(TPMS) is available as an accessory kit.
It must be installed by your authorized
Triumph dealer.
The TPMS display on the instruments
will only be activated when the system
has been installed.
Function
Tire pressure sensors are mounted
to the front and rear wheels. These
sensors measure the air pressure inside
the tire and transmit pressure data to
the instruments. The sensors will not
transmit data until the motorcycle
reaches a speed of approximately
12 mph (20 km/h). Two dashes will be
visible in the system display until the
tire pressure signal is received.
After bring the motorcycle to a stop,
the sensors continue to transmit data
for approximately seven minutes before
switching off. The tire pressure values
remain visible in the system display until
the sensors switch off.
An adhesive label will be mounted to the
wheel rim to indicate the position of the
tire pressure sensor, which is near the
valve.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
