Instruments
38
To select an option:
Push the joystick down/up to select
the required Detail option.
Note
There is a short time delay when
using the joystick to select the option,
and the option then being hidden or
shown in the display screen. Make sure
that the joystick isn't held while the
option is waiting to appear or hide the
information. If the joystick is pressed,
the information then reappears until the
next option is selected.
Once the required Detail option is
chosen, press the joystick center to
confirm.
The Detail options are also
numbered and shown in the right
hand side display panel.
Trip Meters
There are two trip meters that can be
accessed and reset in the information
tray.
A
25:20
hh:mm
02:25
0145
mph
mi
15:53
00
7 4 82
Trip 1
HOLD TO RESET
mi
0
N
1
2
3
4
5
1. Trip symbol
2. Distance traveled
3. Time taken
4. Average speed
5. Trip information tray
To view a specific trip meter:
Push the joystick left/right to scroll
through the information tray items
until Trip 1 meter is shown.
Select Trip 1 or Trip 2 by pushing the
joystick down/up.
Note
Trip 2 meter can be shown or hidden
from the information tray. For more
information, see page 49.
To reset a trip meter:
Select the trip meter to be reset.
Press and hold the joystick center
for more than one second.
The trip meter will then be reset.
The trip meter can also be reset from
the Main menu, see
page 48.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Rocket 3 R and is the answer not in the manual?

Triumph Rocket 3 R Specifications

General IconGeneral
Displacement2458 cc
Bore x Stroke110.2 mm x 85.9 mm
Compression Ratio10.8:1
Max Torque221 Nm @ 4, 000 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveShaft
Gearbox6-speed
SwingarmSingle-sided, cast aluminium
Front Tyre150/80 R17 V
Rear Tyre240/50 R16 V
Seat Height773 mm
Dry Weight291 kg
Wheelbase1677 mm
Engine TypeLiquid-cooled, DOHC, inline 3-cylinder
Max Power165 hp (123 kW) @ 6000 rpm
ExhaustStainless steel 3 into 1 headers with 3 exit silencer
ClutchHydraulic, torque assist
FrameFull aluminium frame
Front SuspensionShowa 47 mm upside-down
Rear SuspensionShowa monoshock with piggyback reservoir, adjustable
Front BrakesBrembo Stylema® 4-piston radial monobloc calipers
Rear BrakesBrembo 4-piston monobloc caliper
Front Wheel17 x 3.5 in
Rear Wheel16 x 7.5 in
Fuel Tank Capacity18 L
Instrument DisplayTFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
